TL092031
TL
Double Gear Hand Winch
Heavy duty steel body, zinc plated.
Hardened steel gears.
Polyester blue webbed strap.
End Type: Safety Snap Hook (on one end of strap)
Mooring hook equipped with a safety pawl.
Resistant to bad weather.
Ideal use on pickup trucks, trailers and other mobile applications.
| WLL(KG) | BS(KG) | webbing specification(mm/m) | Gear Ratio | Way/speed | N.W(KG) | QTY/PCS/CTN |
| 220 | 340 | 25mmx3m | 4.1:1 | 1 way/1 speed | 23 | 12 |
| 250 | 375 | 50mmx6m | 3.2:1 | 1 way/1 speed | 25 | 12 |
| 350 | 525 | 50mmx6m | 3.2:1 | 1 way/1 speed | 25 | 12 |
| 450 | 675 | 50mmx7m | 4.1:1 | 2 ways/1 speed | 24.5 | 8 |
| 550 | 825 | 50mmx7m | 4.1:1 | 2 ways/1 speed | 31 | 8 |
| 600 | 900 | 50mmx7m | 4:1 | 2 ways/1 speed | 32 | 8 |
| 700 | 1050 | 50mmx7m | 4:1 | 2 ways/1 speed | 27 | 6 |
| 800 | 1200 | 50mmx10m | 4:1/8:1 | 2 ways/2 speed | 29 | 6 |
| 900 | 1350 | 50mmx10m | 4:1/8:1 | 2 ways/2 speed | 32 | 6 |
| 1100 | 1650 | 50mmx10m | 4:1/8:1 | 2 ways/2 speed | 32 | 6 |
| 1365 | 2045 | 50mmx10m | 4:1/8:1 | 2 ways/2 speed | 32 | 6 |
| 1600 | 2390 | 50mmx10m | 4:1/8:1 | 2 ways/2 speed | 34 | 6 |
The hand winch is a manual winch with automatic brakes. It is a mechanical tool that pulls the cargo by shaking the winch reel by hand. The gear-driven winch wire rope reel pulls the cargo by rotating a wire rope or weaving belt wound around it. It comes with an automatic brake that makes it safe to operate. When the winch wire rope pulls the cargo and the winch reel remains stationary, the brake employment will automatically open.
