TL025001
TL
Shackle Features:
Universal Design: D Ring Shackle ideal for jeep, ATV, truck, trailer and sport utility vehicle, works well with tow straps, snatch straps, tree savers and snatch blocks.
The threaded locking pin is easy to install and can hold the shackle in place for stability when towing.
The screw pin shackles' shape allows them to bear loads from multiple directions
G209 screw pin anchor shackles meet the performance requirements of Federal Specification RR-C-271G Type IVA, Grade A, Class 2.
US type bow Shackles screw pin G209 details
Shackles Use instruction
Angle loads must be applied in plane of the shackle bow.
Do not use the shackle when there is any visible damages or distortion!
| Side Loading Reduction Chart for screw pin and bolt type Shackle Only | |
| Angle of Side Load from Vertical in-Line of Shackle | Adjusted Work Load Limit |
| 0º-45º in line | 100% of Rated Working Load Limit |
| 45º from in line | 70% of Rated Working Load Limit |
| 90º from in line | 50% of Rated Working Load Limit |
In Line load is applied perpendicular to pin
DO NOT SIDE LOAD ROUND PIN SHACKLE.
Shackle dimensions
| Size | WLL | A | B | C | D | E | F | G | H | I | M | N | Weight |
| (in) | (T) | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | kg |
| 3/16 | 0.3 | 9.65 | 6.35 | 22.4 | 4.85 | 15.2 | 14.2 | 24.9 | 37.3 | 4.06 | 28.4 | 4.85 | 0.022 |
| 1/4 | 0.5 | 11.9 | 7.85 | 28.7 | 6.35 | 19.8 | 15.5 | 32.5 | 46.7 | 4.85 | 35.1 | 6.35 | 0.05 |
| 5/16 | 0.75 | 13.5 | 9.65 | 31 | 7.85 | 21.3 | 19.1 | 37.3 | 53 | 5.6 | 42.4 | 7.85 | 0.08 |
| 3/8 | 1 | 16.8 | 11.2 | 36.6 | 9.65 | 26.2 | 23.1 | 45.2 | 63 | 6.35 | 51.5 | 9.65 | 0.135 |
| 7/16 | 1.5 | 19.1 | 12.7 | 42.9 | 11.2 | 29.5 | 26.9 | 51.5 | 74 | 7.85 | 60.5 | 11.2 | 0.195 |
| 1/2 | 2 | 20.6 | 16 | 47.8 | 12.7 | 33.3 | 30.2 | 58.5 | 83.5 | 9.65 | 68.5 | 12.7 | 0.33 |
| 5/8 | 3.25 | 26.9 | 19.1 | 60.5 | 16 | 42.9 | 38.1 | 74.5 | 106 | 11.2 | 85 | 17.5 | 0.63 |
| 3/4 | 4.75 | 31.8 | 22.4 | 71.5 | 19.1 | 51 | 46 | 89 | 126 | 12.7 | 101 | 20.6 | 1.03 |
| 7/8 | 6.5 | 36.6 | 25.4 | 84 | 22.4 | 58 | 53 | 102 | 148 | 12.7 | 114 | 24.6 | 1.6 |
| 1 | 8.5 | 42.9 | 28.7 | 95.5 | 25.4 | 68.5 | 60.5 | 119 | 167 | 14.2 | 129 | 26.9 | 2.3 |
| 1-1/8 | 9.5 | 46 | 31.8 | 108 | 29.5 | 74 | 68.5 | 131 | 190 | 16 | 142 | 31.8 | 3.2 |
| 1-1/4 | 12 | 51.5 | 35.1 | 119 | 32.8 | 92.5 | 76 | 146 | 210 | 17.5 | 156 | 35.1 | 4.4 |
| 1-3/8 | 13.5 | 57 | 38.1 | 133 | 36.1 | 95 | 84 | 162 | 233 | 19.1 | 174 | 38.1 | 6.2 |
| 1-1/2 | 17 | 60.5 | 41.4 | 146 | 39.1 | 98.5 | 92 | 175 | 254 | 20.6 | 187 | 41.1 | 7.8 |
| 1-3/4 | 25 | 73 | 51 | 178 | 46.7 | 127 | 106 | 225 | 313 | 25.4 | 231 | 57 | 13.8 |
| 2 | 35 | 82.5 | 57 | 197 | 53 | 146 | 122 | 253 | 348 | 31 | 263 | 61 | 20.5 |
| 2-1/2 | 55 | 105 | 70 | 267 | 69 | 184 | 145 | 327 | 453 | 35.1 | 330 | 79.5 | 39 |
