Self Colored
Hot Dip Galvanized
Stainless Steel Available
G-401 Quenched&Tempered
| Item No. | Rope DIA. | Weight Per 100 | Dimensions(in.) | |||||
| (in.) | (lbs.) | A | B | C | D | E | R | |
| TL0255911 | 1/4 | 850 | 1-1/4 | 11/16 | 3/4 | 7/15 | 15-16 | 2-1/4 |
| TL0255912 | 5/16 | 1250 | 1-5/8 | 13/16 | 1 | 1/2 | 1-1/8 | 2-23/32 |
| TL0255913 | 3/8 | 2250 | 2 | 15/16 | 1-1/4 | 3/4 | 1-1/2 | 3-7/16 |
| TL0255914 | 1/2 | 3600 | 2-1/2 | 1-5/16 | 1-1/2 | 7/8 | 1-7/8 | 4-1/4 |
| TL0255915 | 5/8 | 5200 | 3 | 1-9/16 | 1-3/4 | 1-1/16 | 2-3/16 | 5-1/8 |
| TL0255916 | 3/4 | 7200 | 3-1/2 | 1-3/4 | 2 | 1-1/4 | 2-5/8 | 5-25/32 |
Self Colored
Hot Dip Galvanized
Stainless Steel Available
G-401 Quenched&Tempered
| Item No. | Rope DIA. | Weight Per 100 | Dimensions(in.) | |||||
| (in.) | (lbs.) | A | B | C | D | E | R | |
| TL0255911 | 1/4 | 850 | 1-1/4 | 11/16 | 3/4 | 7/15 | 15-16 | 2-1/4 |
| TL0255912 | 5/16 | 1250 | 1-5/8 | 13/16 | 1 | 1/2 | 1-1/8 | 2-23/32 |
| TL0255913 | 3/8 | 2250 | 2 | 15/16 | 1-1/4 | 3/4 | 1-1/2 | 3-7/16 |
| TL0255914 | 1/2 | 3600 | 2-1/2 | 1-5/16 | 1-1/2 | 7/8 | 1-7/8 | 4-1/4 |
| TL0255915 | 5/8 | 5200 | 3 | 1-9/16 | 1-3/4 | 1-1/16 | 2-3/16 | 5-1/8 |
| TL0255916 | 3/4 | 7200 | 3-1/2 | 1-3/4 | 2 | 1-1/4 | 2-5/8 | 5-25/32 |
