Specification
One way sling- width, length,color can customized
| SINGLE PLY ENDLESS WEBBING SLING | ||||||||||||
 | Width of webbing(mm) | COLOR | WLL(kg) | Working Load limit with 1 webbing sling | Working Load limit with 2 webbing sling | |||||||
| Straight lift | Choked lift | β | straight lift up to 45° | choked lift up to 45° | straight lift up to 45°-60° | Choked lift up to 45°-60° | ||||||
| 0°-7° | 7°-45° | 45°-60° | ||||||||||
| 1 | 0.8 | 2 | 1.4 | 1 | 1.4 | 1.12 | 1 | 0.8 | ||||
| 25/30/50 | VIOLET | 1,000 | 1000 | 800 | 2000 | 1400 | 1000 | 1400 | 1120 | 1000 | 800 | |
| 50/60 | GREEN | 2,000 | 2000 | 1600 | 4000 | 2800 | 2000 | 2800 | 2240 | 2000 | 1600 | |
| 75/90 | YELLOW | 3,000 | 3000 | 2400 | 6000 | 4200 | 3000 | 4200 | 3360 | 3000 | 2400 | |
| 100/120 | GREY | 4,000 | 4000 | 3200 | 8000 | 5600 | 4000 | 5600 | 4480 | 4000 | 3200 | |
| 125/150 | RED | 5,000 | 5000 | 4000 | 10000 | 7000 | 5000 | 7000 | 5600 | 5000 | 4000 | |
| 150/180 | BROWN | 6,000 | 6000 | 4800 | 12000 | 8400 | 6000 | 8400 | 6720 | 6000 | 4800 | |
| 200/240 | BLUE | 8,000 | 8000 | 6400 | 16000 | 11200 | 8000 | 11200 | 8960 | 8000 | 6400 | |
| 250/300 | ORANGE | 10,000 | 10000 | 8000 | 20000 | 14000 | 10000 | 14000 | 11200 | 10000 | 8000 | |
Other Option available( 2 ply endless webbing sling, endless webbing sling with one eye)
Specification
One way sling- width, length,color can customized
| SINGLE PLY ENDLESS WEBBING SLING | ||||||||||||
| Width of webbing(mm) | COLOR | WLL(kg) | Working Load limit with 1 webbing sling | Working Load limit with 2 webbing sling | |||||||
| Straight lift | Choked lift | β | straight lift up to 45° | choked lift up to 45° | straight lift up to 45°-60° | Choked lift up to 45°-60° | ||||||
| 0°-7° | 7°-45° | 45°-60° | ||||||||||
| 1 | 0.8 | 2 | 1.4 | 1 | 1.4 | 1.12 | 1 | 0.8 | ||||
| 25/30/50 | VIOLET | 1,000 | 1000 | 800 | 2000 | 1400 | 1000 | 1400 | 1120 | 1000 | 800 | |
| 50/60 | GREEN | 2,000 | 2000 | 1600 | 4000 | 2800 | 2000 | 2800 | 2240 | 2000 | 1600 | |
| 75/90 | YELLOW | 3,000 | 3000 | 2400 | 6000 | 4200 | 3000 | 4200 | 3360 | 3000 | 2400 | |
| 100/120 | GREY | 4,000 | 4000 | 3200 | 8000 | 5600 | 4000 | 5600 | 4480 | 4000 | 3200 | |
| 125/150 | RED | 5,000 | 5000 | 4000 | 10000 | 7000 | 5000 | 7000 | 5600 | 5000 | 4000 | |
| 150/180 | BROWN | 6,000 | 6000 | 4800 | 12000 | 8400 | 6000 | 8400 | 6720 | 6000 | 4800 | |
| 200/240 | BLUE | 8,000 | 8000 | 6400 | 16000 | 11200 | 8000 | 11200 | 8960 | 8000 | 6400 | |
| 250/300 | ORANGE | 10,000 | 10000 | 8000 | 20000 | 14000 | 10000 | 14000 | 11200 | 10000 | 8000 | |
Other Option available( 2 ply endless webbing sling, endless webbing sling with one eye)
