.Forged Super Alloy Steel-Quenched and Tempered
.Suitable for EN818-2 CHAIN
.Individually proof test at 2.5 times Working Load Limited.
.Surface:Powder plastified
.Colour: Red/Yellow
.Marking:SIZE+WLL+CE
.Ultimate load is 4 times at working load limit
| SIZE(MM) | Weight(KG) | WLL(T) | BL(T) | B | C | D | L | T | E |
| 6-8 | 0.71 | 1.12 | 4.48 | 32.5 | 22 | 11.25 | 170 | 34 | 29 |
| 7/8-8 | 1.1 | 2 | 8 | 35.5 | 26 | 12.5 | 210 | 46 | 34 |
| 10-8 | 2 | 3.15 | 12.6 | 42 | 34 | 15 | 247 | 56 | 44 |
| 13-8 | 4 | 5.3 | 21.2 | 50 | 38.5 | 16 | 302 | 69 | 52 |
| 16-8 | 7.3 | 8 | 32 | 61 | 55 | 21.5 | 383 | 86 | 60 |
| 18/20-8 | 11.6 | 12.5 | 50 | 72 | 61 | 26 | 418 | 100 | 83 |
| 22-8 | 16 | 15 | 60 | 95 | 95 | 33 | 587 | 98 | 88 |
| 26-8 | 21.5 | 21.2 | 84.8 | 122 | 115 | 42 | 610 | 110 | 95.5 |
| 32-8 | 79 | 31.5 | 126 | 140 | 126 | 52 | 777 | 166 | 150 |
.Forged Super Alloy Steel-Quenched and Tempered
.Suitable for EN818-2 CHAIN
.Individually proof test at 2.5 times Working Load Limited.
.Surface:Powder plastified
.Colour: Red/Yellow
.Marking:SIZE+WLL+CE
.Ultimate load is 4 times at working load limit
| SIZE(MM) | Weight(KG) | WLL(T) | BL(T) | B | C | D | L | T | E |
| 6-8 | 0.71 | 1.12 | 4.48 | 32.5 | 22 | 11.25 | 170 | 34 | 29 |
| 7/8-8 | 1.1 | 2 | 8 | 35.5 | 26 | 12.5 | 210 | 46 | 34 |
| 10-8 | 2 | 3.15 | 12.6 | 42 | 34 | 15 | 247 | 56 | 44 |
| 13-8 | 4 | 5.3 | 21.2 | 50 | 38.5 | 16 | 302 | 69 | 52 |
| 16-8 | 7.3 | 8 | 32 | 61 | 55 | 21.5 | 383 | 86 | 60 |
| 18/20-8 | 11.6 | 12.5 | 50 | 72 | 61 | 26 | 418 | 100 | 83 |
| 22-8 | 16 | 15 | 60 | 95 | 95 | 33 | 587 | 98 | 88 |
| 26-8 | 21.5 | 21.2 | 84.8 | 122 | 115 | 42 | 610 | 110 | 95.5 |
| 32-8 | 79 | 31.5 | 126 | 140 | 126 | 52 | 777 | 166 | 150 |
